Consistent Hashing

Distributed Systems
04 / 21

A technique that minimizes data redistribution when nodes are added to or removed from a distributed cache or storage cluster.

S1S2S3Key ARequest routes clockwise to next server node
SD blueprint: Consistent Hashing Ring
The Analogy (Read This First)

Imagine a clock face (0-12). Your 3 servers sit at positions 12, 4, and 8. Each piece of data is hashed to a "time" on the clock, and is served by the next server clockwise. When you add a 4th server at position 2, only data between 12 and 2 moves - the rest stays put. With normal hashing, ALL data would move.

Deep Dive Analysis

In a naive distributed cache with N nodes, you route a key by doing `hash(key) % N`. This works perfectly - until you add a node. Now you have N+1 nodes, and `hash(key) % (N+1)` gives entirely different results for almost every key. Every cached item is now on the wrong node. You've just invalidated ~100% of your cache in one go.

Consistent Hashing solves this by placing both servers and keys on a conceptual ring (a circular number line, e.g., 0 to 2^32). Each server owns an arc of the ring. A key is assigned to the first server clockwise from its position on the ring.

When you add a node, only keys in the arc that the new node takes over need to be moved. On average, only 1/N of the data moves (where N is the number of existing nodes).

When you remove a node, only the keys on that node's arc need to be redistributed to the next node clockwise.

Virtual nodes (vnodes): A real system assigns each physical server many positions on the ring (e.g., 150 virtual nodes per server). This ensures even distribution even when servers have different capacities or arrive/depart at different times. Cassandra uses 256 vnodes per server by default.

Key Bullets
  • Only O(K/N) keys need remapping when a node joins or leaves (K = total keys, N = nodes).
  • Virtual nodes solve uneven distribution and make heterogeneous clusters work correctly.
  • Used by: Cassandra, DynamoDB, Memcached (via client-side hashing), Amazon S3, Chord.
  • The load balancing is only probabilistically even; vnodes improve this significantly.
Real-World Examples
Cassandra: automatic token assignment with vnodesAmazon DynamoDB: consistent hashing for partition routingMemcached: client-side consistent hashing libraries (libketama)
